DD Dual Temp Controller

DD Dual Temp Controller

Product Overview

The DD Dual Temp Controller is a digital temperature control unit designed to regulate both heating and cooling equipment in aquariums. It features dual power sockets, allowing independent control of a heater and a cooling device such as a fan or chiller.

The unit includes a waterproof, plastic-coated temperature sensor suitable for marine and freshwater aquariums and provides precise temperature regulation within a defined control range.

Key Features

• Dual heating and cooling control modes
• Two mains power sockets (heater and cooling device)
• Plug and play operation
• Backlit blue LCD display
• Waterproof, plastic-coated temperature sensor
• 2m sensor cable with suction cup mount
• Audible and visual alarm function
• Power-off memory function
• Compatible with D-D Titanium aquarium heaters

Benefits

• Allows simultaneous control of heating and cooling devices
• Precise temperature regulation with adjustable differential
• Alarm system provides notification of temperature deviations
• Suitable for marine and freshwater aquarium systems
• Simple installation without wiring requirements

Specifications

• Product Code: TC125
• Temperature Control Range: 16–40°C
• Temperature Differential Range: 0.3–16.0°C
• Alarm Range: 0.5–5°C from set point
• Resolution: 0.1°C
• Accuracy: ±1°C (30–50°C)
• Power Supply: 220VAC ±10%, 50/60Hz
• Power Consumption: ≤3W
• Heating Control (Resistive Load): Max 1600W
• Cooling Control (Inductive Load): Max 600W
• Operating Humidity Range: 20%–85%
• Display Panel Size: 95 × 50 × 15mm
• Control Socket Size: 160 × 70 × 45mm
• Temperature Sensor Cable Length: 2m
